CLW5041GSSB4 Model technical parameters | |||
Name: | CLW5041GSSB4 | Exterior size(mm): | 5320×1800×2300 |
Chassis: | BJ1042V9JB4-X1 | Container size(mm): | ×× |
Total weight :(kg) | 4155 | Approach angle/ Departure angle(° ) | 18/22,18/20 |
Payload:(kg) | 1490 | Front suspension/rear suspension(mm): | 1100/1370,1100/1620 |
Kerb Mass:(kg) | 2535(Kg) | Max Speed(km/h): | 90 |
Chassis parameters | |||
Chassis: | BJ1042V9JB4-X1 | Axle weight: | 1580/2575 |
Number of axles: | 2 | Fuel Type: | Diesel fuel |
Wheelbase(mm): | 2600,2850,3050 | Fronttread(mm): | 1345,1385,1415 |
Max people in cab: | 2 | Rear tread(mm): | 1240,1340,1280 |
Number of tires: | 6 | Number of spring axle: | 7/5+3 |
Tire Type: | 6.00-14 10PR,6.00-15 10PR,185R15LT | ||
introduction: | 罐体有效容积:1.56立方米,罐体外形尺寸(长×长轴×短轴)(mm):2600,2500×1050×800。防护材料:Q235A,连接方式:侧防护与副梁焊接连接,后防护与车架焊接连接,后部防护断面尺寸(mm):120×50×5,后部防护离地高度(mm):500。随底盘选装前围及车门覆盖件,仅选用轴距2850、2600与罐体长2600、2500一一对应。 |
Engine parameters | |||
Type | Manufacturer | Displacement(ml) | Power(kw) |
4B1-82C40 4A1-68C40 4L18CF YZ4DC1-40 |
安徽全柴动力股份有限公司 安徽全柴动力股份有限公司 山东华源莱动内燃机有限公司 潍柴动力扬州柴油机有限责任公司 |
2270 1809 1809 2160 |
60 50 50 60 |
other parameters |
Introduction: |
