CLW5110GSSD4 Model technical parameters | |||
Name: | CLW5110GSSD4 | Exterior size(mm): | 7000×2100×2450 |
Chassis: | DFA1110SJ11D3 | Container size(mm): | ×× |
Total weight :(kg) | 11495 | Approach angle/ Departure angle(° ) | 20/10 |
Payload:(kg) | 7000 | Front suspension/rear suspension(mm): | 1210/1990 |
Kerb Mass:(kg) | 4300(Kg) | Max Speed(km/h): | 95 |
Chassis parameters | |||
Chassis: | DFA1110SJ11D3 | Axle weight: | 4595/6900 |
Number of axles: | 2 | Fuel Type: | Diesel fuel |
Wheelbase(mm): | 3800 | Fronttread(mm): | 1770,1831,1740,1845,1769,1903 |
Max people in cab: | 3 | Rear tread(mm): | 1640,1586,1610,1680,1629 |
Number of tires: | 6 | Number of spring axle: | 8/10+7,11/9+7 |
Tire Type: | 8.25-20 14PR,8.25R20 14PR | ||
introduction: | 选装新造型前面罩,前保险杠,前组合灯具;罐体有效容积:7.35立方米,介质:水,密度:1000千克/立方米,罐体外形尺寸(长/长轴/短轴)(mm):4200/2000/1300;防护材料:Q235A碳钢,连接方式:左右侧面及后部防护均采用焊接连接,后部防护断面尺寸(mm):100×50,后部防护离地高度(mm):500。 |
Engine parameters | |||
Type | Manufacturer | Displacement(ml) | Power(kw) |
ISB3.9-125E40A CY4102-CE4B CY4102-CE4C YC4E140-42 YN38CRD1 YC4S150-48 YC4FA120-40 |
东风康明斯发动机有限公司 东风朝阳朝柴动力有限公司 东风朝阳朝柴动力有限公司 广西玉柴机器股份有限公司 昆明云内动力股份有限公司 广西玉柴机器股份有限公司 广西玉柴机器股份有限公司 |
3900 3856 3856 4260 3760 3767 2982 |
92 100 91 103 95 110 88 |
