CLW5162GSS4 Model technical parameters | |||
Name: | CLW5162GSS4 | Exterior size(mm): | 8100,7450×2480×3000 |
Chassis: | DFA1160LJ10D4 | Container size(mm): | ×× |
Total weight :(kg) | 15790 | Approach angle/ Departure angle(° ) | 14/13,14/14 |
Payload:(kg) | 9145 | Front suspension/rear suspension(mm): | 1230/2370,1230/2270 |
Kerb Mass:(kg) | 6450(Kg) | Max Speed(km/h): | 100 |
Chassis parameters | |||
Chassis: | DFA1160LJ10D4 | Axle weight: | 5990/9800 |
Number of axles: | 2 | Fuel Type: | Diesel fuel |
Wheelbase(mm): | 3950,4500 | Fronttread(mm): | 1858,1949 |
Max people in cab: | 3 | Rear tread(mm): | 1806,1865 |
Number of tires: | 6 | Number of spring axle: | 8/10+7 |
Tire Type: | 9.00-20 16PR,9.00R20 16PR | ||
introduction: | 运输介质:水,密度:1000千克/立方米;罐体有效容积:9.6立方米,整车长与罐体外形尺寸(长/长轴/短轴)与轴距的对应关系为(mm):8100/5000/2100/1350/4500,7450/4350/2300/1400/3950;侧防护及后下部防护装置均采用Q235A材质,均采用焊接连接,后下部防护尺寸:50*150(mm),离地面高度530mm。ABS系统生产厂家/型号:焦作博瑞克控制技术有限公司/J ABS;文字喷图位置和车辆颜色可变化。 |
Engine parameters | |||
Type | Manufacturer | Displacement(ml) | Power(kw) |
ISD160 43 ISD180 43 |
东风康明斯发动机有限公司 东风康明斯发动机有限公司 |
4500 4500 |
118 132 |
other parameters |
Introduction: |
