CLW5061GSSJ4 Model technical parameters | |||
Name: | CLW5061GSSJ4 | Exterior size(mm): | 5995×1960×2380 |
Chassis: | JX1061TG24 | Container size(mm): | ×× |
Total weight :(kg) | 5880 | Approach angle/ Departure angle(° ) | 20/16 |
Payload:(kg) | 2850,2785 | Front suspension/rear suspension(mm): | 1065/1570 |
Kerb Mass:(kg) | 2900(Kg) | Max Speed(km/h): | 80 |
Chassis parameters | |||
Chassis: | JX1061TG24 | Axle weight: | 2265/3615 |
Number of axles: | 2 | Fuel Type: | Diesel fuel |
Wheelbase(mm): | 3360 | Fronttread(mm): | 1385 |
Max people in cab: | 2,3 | Rear tread(mm): | 1425 |
Number of tires: | 6 | Number of spring axle: | 7/5+5 |
Tire Type: | 7.00R16LT | ||
introduction: | 1,选装驾驶室前围面板,进气格栅,前保险杠及前部灯具。2,运送介质品名:水,介质密度:1000千克/立方米,罐体有效容积:2.9立方米;罐体外形尺寸(长/长轴/轴)(mm):3200/1460/920。防护材料:Q235A碳钢,连接方式:左右侧面及后下部防护均采用焊接连接,后部防护断面尺寸(mm):50×140,后部防护离地高度(mm):440。 |
Engine parameters | |||
Type | Manufacturer | Displacement(ml) | Power(kw) |
JX493ZLQ4 | 江铃汽车股份有限公司 | 2771 | 80 |
other parameters |
Introduction: |
more Picture: |
