| CLW5035TQP5 Model technical parameters | |||
| Name: | CLW5035TQP5 | Exterior size(mm): | 5210×1840×2150 |
| Chassis: | EQ1031SJ50Q6WXP | Container size(mm): | 3300×1750×600 |
| Total weight :(kg) | 3360 | Approach angle/ Departure angle(° ) | 34/24 |
| Payload:(kg) | 1495 | Front suspension/rear suspension(mm): | 545/1365 |
| Kerb Mass:(kg) | 1735(Kg) | Max Speed(km/h): | 80 |
| Chassis parameters | |||
| Chassis: | EQ1031SJ50Q6WXP | Axle weight: | 1345/2015 |
| Number of axles: | 2 | Fuel Type: | Gasoline |
| Wheelbase(mm): | 3300 | Fronttread(mm): | 1430 |
| Max people in cab: | 2 | Rear tread(mm): | 1445 |
| Number of tires: | 6 | Number of spring axle: | 6/7+4 |
| Tire Type: | 185R14LT | ||
| introduction: | 该车为危险货物运输车,主要用于运输具有独立容器(瓶)包装的液化石油气,丁烷,乙炔,乙烷,丙烷,丁烯,打火机或打火机加油器,二氧化碳,压缩氧(氮,空气,氦,氩,氖);压缩煤气,氯气,类项号:2.1,2.2,2.3;该车安装带有卫星定位功能的行驶记录仪,仅采用前盘制动器和安装ABS以及前置消声器的底盘,采用子午线轮胎,安装限速装置,限速80km/h, ABS型号:ABS/ASR-24V-4S/4M,ABS型号厂家:襄阳东风隆诚机械有限责任公司。 | ||
| Engine parameters | |||
| Type | Manufacturer | Displacement(ml) | Power(kw) |
| LJ469Q-1AEC | 柳州五菱柳机动力有限公司 | 1249 | 64 |
| other parameters |
| Introduction: |
| more Picture: |
| ※ Need more information or pictures?please contact us and we will provide best service!。 |
