sx5251jsqgp5 Model technical parameters | |||
Name: | sx5251jsqgp5 | Exterior size(mm): | 10600,11500,12000×2500,2550×3650,3850 |
Chassis: | SX1250GP5 | Container size(mm): | 6650,6950,7500,7800,8000,8400×2300,2400×550,600 |
Total weight :(kg) | 24500 | Approach angle/ Departure angle(° ) | 26/11 |
Payload:(kg) | 9435,8605 | Front suspension/rear suspension(mm): | 1450/3150,1450/3100,1450/3450,1450/3400 |
Kerb Mass:(kg) | 14870,15700(Kg) | Max Speed(km/h): | 85 |
Chassis parameters | |||
Chassis: | SX1250GP5 | Axle weight: | 6500/18000(二轴组) |
Number of axles: | 3 | Fuel Type: | Diesel fuel |
Wheelbase(mm): | 3400+1300,3600+1300,3600+1350,3800+1300,3800+1350,5800+1300,4700+1300,4700+1350,5300+1300,5300+1350,5800+1350,4375+1350,4375+1300 | Fronttread(mm): | 1970,1940,1900 |
Max people in cab: | 3 | Rear tread(mm): | 1750/1750,1860/1860,1775/1775 |
Number of tires: | 10 | Number of spring axle: | 9/10 |
Tire Type: | 10.00-20,10.00R20,11.00-20,11.00R20,10.00-20 18PR,10.00R20 18PR,11.00-20 18PR,11.00R20 18PR | ||
introduction: | 1.选装上/中座椅操作,可选装直臂式或折臂式吊机,直臂式吊机型号:吊机重量(kg)/大起升载荷(kg)分别为:1.(SQS250,QYS-10,SPS25000,ZLC2500,nicoleV1000)/4000/10000;2.(SQS300,QYS-12,SPS30000,ZLC3000,nicoleV1200)/4500/12000;JSQ300/4500/12000.折臂式吊机的分别为:1,(SQZ250,QYS-10Z)/4000/10000; 2,(SQZ300,QYS-12Z)/4500/12000.2.该车侧后防护材料材质为Q235,侧防护连接方式为螺栓连接+焊接连接,后防护连接方式为螺栓连接,后防护离地高440mm,断面尺寸120×50mm.3.ABS系统生产厂家:西安正昌电子有限责任公司,型号:ZQFB-V.4.整车长/轴距/后悬对应关系(mm):10600/4700+1300,4700+1350/3150,3100;11500/5300+1300,5300+1350/3450,3400;12000/5800+1300,5800+1350/3450,3400.5.安装具有卫星定位功能的行驶记录仪.6.发动机/油耗值(L/100km):WP7.270E51/37.2,WP6.245E50/37.2,YC6A270-50/37.2.YC6JA240-50/37.2,WP7.340E53/37.2;7.随底盘选装驾驶室前部灯具,前围,前保险杠,侧围,后视镜;选装驾驶室两侧喷涂\"X6\"字样及图案. |
Engine parameters | |||
Type | Manufacturer | Displacement(ml) | Power(kw) |
WP7.270E51 WP6.245E50 YC6A270-50 WP7.300E51 YC6JA240-50 WP7.340E53 |
潍柴动力股份有限公司 潍柴(潍坊)中型柴油机有限公司 广西玉柴机器股份有限公司 潍柴动力股份有限公司 广西玉柴机器股份有限公司 潍柴动力股份有限公司 |
7470 6750 7520 7470 6870 7470 |
199/270 180/244 199/270 220/299 177/240 250/340 |
other parameters |
Introduction: |
more Picture: |
※ Need more information or pictures?please contact us and we will provide best service!。 |
